Kuebler Elektronski brojač Codix 131 dvokanalni ; 6.131.012.8XX
Pulse counter, double-channel for PNP, NPN and high voltage applications. The Codix 131 is a battery powered simple pulse counter with differential or direction...
Price on request
Pulse counter, double-channel for PNP, NPN and high voltage applications.
The Codix 131 is a battery powered simple pulse counter with differential or direction input, 8 digit LCD display, optional backlight, for NPN, PNP and high voltage applications.
Efficient
- High-quality LCD display with 8 mm digit height.
- Counting direction, adding and subtracting via counting direction or differential input.
- Battery life of 8 years.
- Optional display backlighting.
- Counting frequency max. 12 kHz.
- High IP65 protection
- Screw terminal connection in 5 mm pitch.
- Reset button can be locked via Reset Enable input.
- Depending on version for positive or negative counting edges.
- High-voltage version for 10 to 260 V AC/DC voltage pulses.
- Large 8-digit LCD display with 8 mm digit height.
| Mechanical | |
|---|---|
| Model | electronic |
| Dimension 1 | 48 x 24 mm | 45 x 22 mm |
| Protection level | IP65 |
| Working temperature | -10 °C ... +65 °C |
| Weight | 50 g |
| Reset | electronic |
| Electrical | |
|---|---|
| Supply voltage | via battery |
| Signal input |
Digital inputs 0...0,7 VDC, NPN 4...30 VDC, PNP |
-
131 en
