- Communication Interfaces: Micro-USB Type-B, RS485 and IEEE802.15.4

- Protocols: Modbus RTU and NOVUS-Air

- Network Topology: Point-to-point, star and tree

- Wireless Features: ISM 2.4 GHz, DSSS, OQPSK, 15 channels, Tx Power 20dBm, Sensitivity -96dBm, Line-of-Sight Range 1000 m

- Security Features: AES-CBC-128 Encryption

- Modes of Operation: RS485-Master, USB-Master, Multi-Master, RS485-Slave

- Firmware Upgrade: Yes, by USB

- Power Supply: 10-30 Vdc

- Programmable Functions: Mode of Operation and Communication Settings

- Configuration: Yes, via USB with DigiConfig

- Housing: Injected in PA66

- Dimensions:
  99.5 x 114 x 17.5 mm + Antenna 105 mm
  3.92 x 4.49 x 0.69 in + Antenna 4.13 in

- Operating Range:
  Temperature -10 to 70 °C (14 to 158 °F)
  Humidity 80% up to 30 °C (86 °F)

- Protection Rating: IP20

- Electric Protection: Reverse Polarity

- Certifications: CE, FCC, ANATEL (01818-11-07089)

DigiConfig - Software to configure transmitters and gateways
DigiConfig is an easy-to-use software for parameterizing and diagnosing transmitters and gateways with a Modbus RTU serial interface, so that they can later be connected to any supervisory or control system.The devices are physically connected to the computer via an RS485 network. For this connection, you can use a USB cable, an RS232-RS485 converter or a USB-RS485 converter. The communication protocol used between the computer and equipment is Modbus RTU.
Download software here.
